High-pressure water mist systems

Customizable, all-in-one high-pressure units for water mist

High-pressure water mist is critical to a wide range of processes, including humidification, dust suppression, fire suppression, adiabatic cooling, odor control, and disinfection. Water mist systems are a versatile, cost-effective, and environmentally responsible choice that offer several advantages compared to alternative solutions. They are relatively simple to install and maintain in new or existing applications.

Compared with sprinkler systems, they consume far less water and cause much less damage. Besides, they are non – toxic and harmless.
We simplify the application of water mist. These systems are designed to achieve easy installation, optimal energy efficiency, simple operation and maintenance, as well as convenient automation.
Our high – pressure water mist systems can be customized according to the specific needs of customers. All systems are equipped with necessary safety features and can be configured in line with customers’ requirements for water mist volume, control, and automation.

Features and benefits

Plug-and-play water mist systems that save energy & maintenance

  • Designed for maximum performance in minimum space
  • Built-in safety features to protect system in case of water outages or excess pressure
  • You choose: flow range, valves, controls
  • Ready to connect to water and electrical supplies
  • Built, tested and certified prior to shipping

Powered by BHP high-pressure pumps

  • Market-leading energy efficiency
  • Zero risk of oil contamination
  • Long service intervals – minimum 8,000 hours

Integrated high-pressure valves and controls

  • Corrosion and high-temperature resistant, dirt tolerant
  • Low pressure drop
  • Easy maintenance while still connected to the system

Product range

High-pressure water mist systems

Pressure range: Max outlet pressure: 140 barg

Flow range: 112L/Min

HP pump:: BHP80

Medium:pure water/technical water

Water filtration:10 μm absolute, β ≥ 5,000

Power: 30KW

Electrical Control: It is equipped with a standard three-phase 380V, 50Hz asynchronous motor.There is a PLC control cabinet, which enables automatic control.

High-pressure water mist systems

Pressure range: Max outlet pressure: 140 barg

Flow range: 224L/Min

HP pump:: BHP80

Medium:pure water/technical water

Water filtration:10 μm absolute, β ≥ 5,000

Power: 60KW

Electrical Control: It is equipped with a standard three-phase 380V, 50Hz asynchronous motor.There is a PLC control cabinet, which enables automatic control.

High-pressure water mist systems

Pressure range: Max outlet pressure: 140 barg

Flow range: 448L/Min

HP pump:: BHP80

Medium:pure water/technical water

Water filtration:10 μm absolute, β ≥ 5,000

Power: 120KW

Electrical Control: It is equipped with a standard three-phase 380V, 50Hz asynchronous motor.There is a PLC control cabinet, which enables automatic control.

High-pressure water mist systems

Pressure range: Max outlet pressure: 140 barg

Flow range: 784L/Min

HP pump:: BHP80

Medium:pure water/technical water

Water filtration:10 μm absolute, β ≥ 5,000

Power: 210KW

Electrical Control: It is equipped with a standard three-phase 380V, 50Hz asynchronous motor.There is a PLC control cabinet, which enables automatic control.

♥High – pressure water systems are customized systems. If you have any other technical requirements, please contact us.
